PARTIAL DUAL-ZONE

This PRODUCT is PARTIAL DUAL-ZONE.

Let's say you are using the GPS and you want to listen to a CD or the Radio, you will need to go to Radio or CD mode to listen to your music, but the GPS will keep giving directives in the background to turn & etc.The volume of the music will lower when the GPS gives you directives.

You cannot listen to a CD or the RADIO, while watching the GPS Map.

Features

Specification

OSD On-Screen-Display FunctionOSD Picture Control: Brightness/Contrast/Hue/Saturation/ and SharpnessOSD display Clock, Title, Time, Chapter, SubtitleClock: two Times system: Europe Time (24 hours setup); America Time (12 hour setup AM & PM)Repeat, Intro, Random, Resume function Multi-language support:OSD Language: English, German, Spanish, French, Portuguese & ItalianAudio Language: English, German, Spanish, French, Portuguese & ItalianSubtitle Language: English, German, Spanish, French, Portuguese & ItalianMenu Language: English, German, Spanish, French, Portuguese & Italian

Built-in AM/FM Radio TunerAM/FM-MPX 2 Band RadioPLL Synthesizer TunerUS/Canada:      FM1-3  (87.50Mhz - 107.90Mhz)  (200Khz Increment)AM1-2 (530Khz - 1710Khz)  (10Khz Increment)Europe:             FM1-3  (87.50Mhz - 108.00Mhz)  (50Khz Increment)AM1-2 (522Khz - 1620Khz)  (9Khz Increment)  Auto Scan/Preset Scan Memory: 30 Station MemoryRadio Freq. Select for USA1, USA2, JAPAN, RUSSIA, and EUROPERDS-EON function MO/ST & LO/DX SelectRadio Antenna Input

Bluetooth System Build-In Microphone for Bluetooth at front PanelTouch Screen Function interface for easy accessOne touch button to answer a phone call through your car speakers Bluetooth Support Touch Screen Number-Keypad to dial (for Outgoing Call)Bluetooth Hand-free/Cell phone switching (See Manual on Page.42)“Change” Call Transfer Function (transfer the audio from unit to mobile phone for privacy reason.)Bluetooth Call and Re-Call FunctionVoice-Dialing Function (Optional)External Mic Input port for BluetoothDisplay Bluetooth Paring and Connection status, Call status and Caller’s IDBluetooth Note (Contact book): Dialed call, Received call & Missed callSupport Bluetooth Audio

Audio Spec. and Typical InterfaceAuxiliary Audio Input Jack (Front Panel)Auxiliary Audio Input (Rear-RCA) (L/R)Auxiliary Video Input (Rear-RCA)Car Backing Up Camera Video Input (Rear-RCA)-Camera Mirror image selection (L & R)Video Output (2x) (Rear-RCA)Audio FR/FL/RR/RL Pre-amplified Line-Out (Rear-RCA)-Front Channel RCA Line-Out (L/R) (Rear-RCA)-Rear Channel RCA Line-Out (L/R) (Rear-RCA)Built-in Amplifier FR/FL/RR/RL  4-Channel Audio Output-Front Channel Speaker Line-Out (L/R) -Rear Channel Speaker Line-Out (L/R) Bass/ Treble/Balance/Fader/Loudness Control/Volume control (Adjustable) EQ Preset: Pop / Rock & ClassicCD/MP3/USB/SD Mode: Music Surround and EQ Setting (Setup through remote ZOOM button)-Surround setting (Concert, Church, Passive, Wide & Live)-EQ setting (Classic, Rock, Jazz, Pop & User)Power Output: Max 240 watts ( 60w x 4Chan.)

Package Content

Power SupplyPower Supply:  DC12 VoltsGround System:  Negative GroundCurrent Drain: less than 10 Amperes (Max.)Gross Weight: About 3.30 kgNet Weigh:  About 2.58 kgInstall Dimension Size (mm): 178 x 153 x 101

Accessories: Standard Accessories1 x Usb Interface Cable 1 x Remote control 1 x Wire Harness1 x User's Manual
